DescriptionModelTUF GAMING B660-PLUS WIFI D4News & Updates2024/08/12: The new BIOS with Intel microcode (0x129) enhancing the stability of Intel Core 13th and 14th Gen desktop processors is now available. Please visit support site for the latest BIOS updates.CPUIntel® Socket LGA1700 for 13th Gen Intel® Core™ Processors & 12th Gen Intel® Core™, Pentium® Gold and Celeron® ProcessorsSupports Intel® Turbo Boost Technology 2.0 and Intel® Turbo Boost Max Technology 3.0*** Refer to www.asus.com for CPU support list.** Intel® Turbo Boost Max Technology 3.0 support depends on the CPU types.ChipsetIntel® B660 ChipsetMemory4 x DIMM, Max. 128GB, DDR4 5333(OC)/5066(OC)/5000(OC)/4800(OC)/4600(OC)/4400(OC)/4266(OC)/4000(OC)/3733(OC)/3600(OC)/3466(OC)/3400(OC)/3333(OC)/3200/3000/2933/2800/2666/2400/2133 Non-ECC, Un-buffered Memory*Dual Channel Memory ArchitectureSupports Intel® Extreme Memory Profile (XMP)OptiMem II*Actual memory data rate depends on the CPU types and DRAM modules, for more information refer to www.asus.com for the Memory QVL (Qualified Vendors Lists).Graphics1 x DisplayPort**1 x HDMI® port**** Graphics specifications may vary between CPU types. Please refer to www.intel.com for any updates.**Supports 4K@60Hz as specified in DisplayPort 1.4.***Supports 4K@60Hz as specified in HDMI 2.1.Expansion SlotsIntel® 13th & 12th Gen Processors1 x PCIe 5.0/4.0/3.0 x16 slot(s)Intel® B660 Chipset*1 x PCIe 3.0 x16 slot (supports x4 mode)2 x PCIe 3.0 x1 slots* Supports Intel® Optane Memory H Series on PCH-attached PCIe slotStorageTotal supports 3 x M.2 slots and 4 x SATA 6Gb/s ports*Intel® 13th & 12th Gen ProcessorsM.2_1 slot (Key M), type 2242/2260/2280/22110– Intel® 12th Gen processors support PCIe 4.0 x4 mode.Intel® B660 Chipset**M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x2 mode)M.2_3 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 4.0 x4 mode)4 x SATA 6Gb/s ports* Intel® Rapid Storage Technology supports SATA RAID 0/1/5/10.** Intel® Rapid Storage Technology supports Intel® Optane Memory H Series on PCH attached M.2 slots.Ethernet1 x Intel® 2.5Gb EthernetTUF LANGuardWireless & BluetoothWi-Fi 62×2 Wi-Fi 6 (802.11 a/b/g/n/ac/ax)Supports 2.4/5GHz frequency bandBluetooth v5.2USBRear USB (Total 6 ports)1 x USB 3.2 Gen 2×2 port(s) (1 x USB Type-C®)1 x USB 3.2 Gen 2 port(s) (1 x Type-A)3 x USB 3.2 Gen 1 port(s) (3 x Type-A)1 x USB 2.0 port(s) (1 x Type-A)Front USB (Total 7 ports)1 x USB 3.2 Gen 2 connector (supports USB Type-C®)1 x USB 3.2 Gen 1 header(s) support(s) additional 2 USB 3.2 Gen 1 ports2 x USB 2.0 header(s) support(s) additional 4 USB 2.0 portsAudioRealtek 7.1 Surround Sound High Definition Audio CODEC*– Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking– Supports up to 24-Bit/192 kHz playbackAudio Features– Rear optical S/PDIF out port– Premium audio capacitors– Dedicated audio PCB layers– Audio coverBack Panel I/O Ports1 x USB 3.2 Gen 2×2 port(s) (1 x USB Type-C®)1 x USB 3.2 Gen 2 port(s) (1 x Type-A)3 x USB 3.2 Gen 1 port(s) (3 x Type-A)1 x USB 2.0 port(s) (1 x Type-A)1 x DisplayPort1 x HDMI® port1 x Wi-Fi Module1 x Intel® 2.5Gb Ethernet port5 x Audio jacks1 x Optical S/PDIF out portInternal I/O ConnectorsFan and Cooling related1 x 4-pin CPU Fan header(s)1 x 4-pin CPU OPT Fan header(s)1 x 4-pin AIO Pump header(s)3 x 4-pin Chassis Fan header(s)Power related1 x 24-pin Main Power connector1 x 8-pin 12V Power connector1 x 4-pin 12V Power connectorStorage related3 x M.2 slots (Key M)4 x SATA 6Gb/s portsUSB1 x USB 3.2 Gen 2 connector (support(s) USB Type-C®)1 x USB 3.2 Gen 1 header(s) support(s) additional 2 USB 3.2 Gen 1 ports2 x USB 2.0 header(s) support(s) additional 4 USB 2.0 portsMiscellaneous3 x Addressable Gen 2 header(s)1 x AURA RGB header(s)1 x Clear CMOS header1 x COM Port header1 x Front Panel Audio header (AAFP)1 x 20-3 pin System Panel header with Chassis intrude function1 x Thunderbolt™ headerSpecial FeaturesASUS TUF PROTECTION– DIGI VRM (- Digital power design with DrMOS)– Enhanced DRAM Overcurrent Protection– ESD Guards– TUF LANGuard– Overvoltage Protection– Safeslot– Stainless-Steel Back I/OASUS Q-Design– M.2 Q-Latch– Q-DIMM– Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow green])– Q-SlotASUS Thermal Solution– M.2 heatsink– VRM heatsink designASUS EZ DIY– CPU Socket lever protector– ProCool– Pre-mounted I/O shield– SafeDIMMAURA Sync– AURA RGB header(s)– Addressable Gen 2 header(s)Software FeaturesASUS Exclusive SoftwareArmoury Crate– AURA Creator– AURA Sync– Fan Xpert 4– Two-Way AI Noise CancelationAI Suite 3– Performance And Power Saving UtilityTurboV EVOEPUDIGI VRMTUF GAMING CPU-ZDTS Audio ProcessingMyAsusNorton Anti-virus software (Free Trial version)WinRARUEFI BIOSASUS EZ DIY– ASUS CrashFree BIOS 3– ASUS EZ Flash 3– ASUS UEFI BIOS EZ ModeBIOS128 Mb ROM, UEFI AMI BIOSManageabilityWOL by PME, PXEAccessoriesCables2 x SATA 6Gb/s cablesMiscellaneous1 x ASUS Wi-Fi moving antennas2 x M.2 Rubber Package(s)1 x M.2 SSD screw package(s)Installation Media1 x Support DVDDocumentation1 x TUF Certification card1 x User guideOperating SystemWindows® 11 64-bit, Windows® 10 64-bitForm FactorATX Form Factor12 inch x 9.6 inch ( 30.5 cm x 24.4 cm )
